Lucoled EL31-W65 6500K, 2.88W, 327lm

• 5 years warranty*
• Lucolense narrow beam technology
• High efficacy
• Constant Current Technology
• Narrow white binning

Lucoled Edge Lighting EL31 modules offer a high quality and efficient solution for
single-sided lightboxes with a depth of 50-100 mm and double-sided lightboxes with a
depth of 100-150 mm, max. 1000 mm wide.

Lucoled EL31 uses patented light reflection technology to evenly illuminate single and
double-sided medium size light boxes and signs. The licensed technology is based on
the face being illuminated by over 70% indirect, internally reflecting, light transmitted by
narrow beam flare lenses. The modules are mounted on the sides of the box, directing a
beam of light at the opposite side. The reflecting light evenly illuminates the face.
EL31 is ideal for medium size rectangular shaped signs. The individual modules are
normally positioned on opposite sides on the longest side of the sign
